Upgraded Fuel/Timing Calibrator For Oversized Injectors (4Cyl. ONLY)
Upgraded Fuel/Timing Calibrator For Oversized Injectors



Our Price: $549.96

Part Number: 1020203
Qty:

Details


Upgraded Fuel/Timing Calibrator For Oversized Injectors (4 Cylinders ONLY)

For 4 Cylinder Tacomas and 4Runners using larger than stock fuel injectors. This unit calibrates the 0-5 V MAF sensor signal and intercepts the variable reluctance cam and crank sensor signals. This unit has an internal enrichment module that works with either narrowband O2 sensor or wideband air/fuel sensors. The module allows a richer fuel mixture in boost at part throttle.

The range of adjustment is +/- 2.5 V on the MAF sensor signal. The absolute maximum allowable increase in injector size is 100%. We don't recommend going that large, we recommend a maximum of no more than 50% increase over stock cc volume. The R4 software is included with this unit.

NOTE: This Unit DOES NOT Come Pre-Programmed And WILL NOT Work With 6 Cylinder Applications.

*NOT STREET LEGAL IN CALIFORNIA

Contact our Tech support line for further information: 928-855-6341.

Check out www.LCEngineering.com for New Products, Tech Articles,
Specials & Monthly Newsletters!

Note: Images are for illustration purposes only. Images MAY NOT represent the product listed. Please contact Customer Service with any questions or concerns: 928-505-2501.
