Weber 38 Carb Kit w/K&N & Billet Cleaner - 20R/22R
Weber 38 Carb Kit w/K&N & Billet Cleaner - 20R/22R

Our Price: $599.95

Part Number: 1030033

Would You Like To Add...

Fuel Pressure Regulator & Gauge?*:


Qty:
Details Fitment Instructions


Weber 38 Carb Kit

(K&N & Billet Cleaner)

Kit Includes:

  • Weber 38 Carburetor Kit, see Part #: 1030030
  • Billet Air Cleaner Assembly, see Part #: 1034033

Weber 38 Carburetor Kit

Unleash the sheer power of your performance vehicle with the Weber 38 Carburetor. Manufactured to deliver maximum speed and horsepower, the Weber 38 is a two-barrel synchronous electric choke carburetor. Due to its impressive performance output, this carburetor is used and trusted by countless racers that require top performance from their four-cylinder engine.

If you've got a modified ride, then the 38 deserves your attention. This carburetor guarantees incredibly fast acceleration and increased low-end torque. Jump out to an early lead and keep it with the supreme air and fuel flow of the 38. Because the 38 carb incorporates a two-barrel synchronous design, your performance engine gets the excellent air flow it needs. Both barrels simultaneously feed the cylinders, and if you've got a modified car, then you know your vehicle can get hungry. With twice as much oxygen and fuel entering your engine at any given moment, your vehicle receives the extra input it needs to reach its maximum output. Unlock your vehicle's full potential and get a 38 Weber today!


Main Jet 145
Secondary Jet 145
Primary Idle 45
Secondary Idle 45
Air Correction (Primary) 185
Air Correction (Secondary) 185
Pump Nozzle 70

NOTE: Requires 2.5 - 3 lbs of fuel pressure, see regulator kit Part #: 1035056. Pre 1985 trucks may have clearance issues with the hood. Body lift or modification may be necessary. If you wish not to modify your vehicle, you may want to look at 1030069 or 1030030.This carburetor does not come with provisions to run a kick-down cable for an automatic transmission. If your Kick Down cable attaches to the Bell Crank, you will not be affected. If it attaches to the carb, modifications will be needed. Most are to the Bell Crank from the factory. Factory fuel line from the mechanical pump is roughly 1/16" smaller than Weber Regulator/Carb fuel line. Slight pressure is all that is needed to fit the smaller line

Pro Billet Air Cleaner w/K&N Air Filter

The Pro Billet Air Cleaner Kit is a bolt-on upgrade for your Weber two barrel carburetors. With twice the filter area as the stock Weber filter. This air cleaner requires no adapters or modification to bolt directly to you Weber 32/36 or 38 carburetor. The kit also comes with a washable and reusable K&N air filter element with the million mile limited warranty. A polished Billet top set this filter apart from others. Made in the USA The Billet Air Cleaner looks great and performs just s well as it looks. All LC Weber downdraft Carb Kits can be upgraded to use the Pro Billet Air Cleaner.

NOTE: Pre 1985 trucks may have clearance issues with the hood. Body lift or modification may be necessary. If you wish not to modify your vehicle, you may want to look at Part #: 1030069 or 1030030.

Weber carb adapter plates have been known to leak, therefore LC Engineering came up with a design that not only seals perfectly, but improves horsepower, due to its spiral cut design, allowing for better air / fuel atomization.

  • LC Engineering Pro Spiral Spacer - 1" Weber Carb. Spacer kit, see Part #: 1033023
  • LC Engineering Spiral Adapter - Weber to 22R Stock Manifold, see Part #: 1033028
  • LC Engineering Spiral Adapter - Stock 22R Carb. to Weber Flange, see Part #: 1033060

Related Weber 38 Kits:

  • Weber 38 Carburetor Only 20R/22R Electric Choke, see Part #: 1030037
  • Weber 38 Carburetor Only 20R/22R Manual Choke, see Part #: 1030038
  • Weber 38 Carburetor Kit With Electric Choke - 20R/22R, see Part #: 1030030
  • Weber 38 Carburetor Kit With Manual Choke 20R/22R, see Part #: 1030034
  • Weber 38 Carburetor Performance Package With Manual Choke, see Part #: 1030022
  • Weber 38 Carburetor Performance Package With Electric Choke, see Part #: 1030023
  • Weber 38 Carb Kit w/K&N & Billet Cleaner - 20R/22R, see Part #: 1030033
  • Weber 38 Carb Kit w/K&N Filter (11"x2") - 20R/22R, see Part #: 1030027
  • Weber 38 Carburetor Performance Package 22R, see Part #: 1030008
  • Weber 38 Carb & Intake Performance Package - 22R with Stock Weber Air Cleaner, see Part #: 1030069
  • Weber 38 Carb & Intake Performance Package 20R (Electric Choke), see Part #: 1030006
  • Weber 38 Carb & Intake Performance Package 20R (Manual Choke), see Part #: 1030009
  • Weber 38 Carb & Intake Performance Package 22R, see Part #: 1030045
  • Weber 38 Carb & Intake Performance Package - 22R, see Part #: 1030042

This product should not be used in a manner that violates Federal EPA Laws.


Contact our Tech Support Line for further information at 928-855-6341.

Check out LCEngineering.com for New Products, Tech Articles, Specials & Monthly Newsletters!

Note: Images are for illustration purposes only. Images may not represent the product listed. Please contact customer service with any questions or concerns: 1-928-505-2501.
